Multi Mill

Get a Price/Quote

About Multi Mill

Discover the praiseworthy Multi Mill, a hot-selling, world-class machine engineered for excellence in your industrial workspace. Crafted with unrivaled stainless steel and an automatic grade, this robust model operates on a frequency of 50-60 MHz and a voltage of 220-440V, ensuring optimal performance every cycle. Weighing approximately 270 kg and sized at 880 x 1050 x 1750mm, its suitable for diverse applications. As Indias leading manufacturer, service provider, and supplier, we offer limited stockexplore the Multi Mill and upgrade your production capabilities today.

Multi Mill Application & Advantage Highlights

Multi Mills are perfect for pharmaceutical, chemical, cosmetic, and food processing environments, excelling in wet and dry granulation, pulverization, and milling. Suited for laboratories and large-scale production units, these machines deliver unmatched efficiency and versatility. Their automatic operation and robust design provide increased safety and reliability, ensuring smooth processing and lower maintenance. With their stainless steel build and flexibility, Multi Mills offer an advantageous solution for demanding applications requiring strict hygiene and consistent performance.

Multi Mill Packaging, Delivery & Sample Policy

We offer industry-standard packaging to safeguard the Multi Mill during dispatching and transportation. Shipping rates are highly competitive, with quick delivery times tailored to your schedule. Our dispatching team ensures careful handling for optimal product integrity upon arrival. For new customers, a transparent sample policy is available, allowing evaluation before purchase. Each order is tracked throughout to guarantee prompt delivery, making the entire process seamless from quotation to installation.

Parameter	Specification
MODEL	3HP Belt Drive cGMP
MOC	Contact parts SS316 & Non-contact parts SS304
ROTOR SPEED	750/1150/1800/2800 RPM
MOTOR	3HP/1440 RPM/415V/50Hz/3ph
ROTOR ASSEMBLY DIA	260 mm (Approx.)
BEATERS	12 nos. knife and impact edges, 2 scraper blades
SCREEN DIMENSION	Dia. 263 mm (ID) x Ht. 140 mm (H)
STARTER	DOL with reversible switch
OUTPUT	50 kgs. to 250kgs./hour depending upon the product and reduction required in size
MATERIAL CHARGING	1490 mm (Approx.)
MATERIAL DISCHARGING	780 mm (Approx.)
OVERALL DIMENSIONS	880 x 1050 x 1750 mm ht. (for Direct drive arrangement ht. is 2000 mm)
NET WEIGHT	270kg (Approx.)
GROSS WEIGHT	450kg (Approx.)
DOCUMENTATION	Documentation like DQ, IQ, OQ, and FAT provided with the machine.
